NATS
Learn how to install and use NATS
Get started
NATS is a simple, secure and high performance open source data layer for cloud native applications, IoT messaging, and microservices architectures.
Before exploring the chart characteristics, let’s start by deploying the default configuration:
helm install <release-name> oci://dp.apps.rancher.io/charts/nats \
--set global.imagePullSecrets={application-collection}
Please check our authentication guide if you need to configure Application Collection OCI credentials in your Kubernetes cluster.
Chart overview
The NATS Helm chart distributed in Application Collection is based on the NATS Helm chart and adapted to include our best practices. As such, any chart-related documentation provided by upstream will work out of the box with our chart. Additionally to the upstream chart repository, you can check the official NATS documentation here.
By default, the chart will deploy a single NATS Server replica and a single-pod deployment with nats-box, a container image shipping utilities to interact with NATS.
Chart configuration
To view the supported configuration options and documentation, run:
helm show values oci://dp.apps.rancher.io/charts/nats
Clustering configuration
NATS Clustering can be activated via Helm chart parameters. It defaults to 3 replicas:
config:
cluster:
enabled: false
# must be 2 or higher when jetstream is enabled
replicas: 3
As an example, to configure a 2-replicas NATS cluster, you would install the Helm chart providing the following command line flags:
helm install <release-name> oci://dp.apps.rancher.io/charts/nats \
--set global.imagePullSecrets={application-collection} \
--set config.cluster.enabled=true,config.cluster.replicas=2
Activate JetStream
JetStream capabilities can also be activated in a simple manner via Helm chart parameters.
Following with the example from the section above, you would install the Helm chart providing the following values file (nats.yaml):
config:
cluster:
enabled: true
replicas: 2
jetstream:
enabled: true
helm install <release-name> oci://dp.apps.rancher.io/charts/nats \
--set global.imagePullSecrets={application-collection} \
--values nats.yaml
Or equivalently, as command line flags:
helm install <release-name> oci://dp.apps.rancher.io/charts/nats \
--set global.imagePullSecrets={application-collection} \
--set config.cluster.enabled=true,config.cluster.replicas=2 \
--set config.jetstream.enabled=true
When JetStream is active, messages are persisted and can be replayed at a later time. The following command creates a stream associated to the “test” subject and sends 2 messages:
$ kubectl exec -it deployment/<release-name>-box -- nats bench test --js --pub=1 --msgs=2
15:20:01 Starting JetStream benchmark [subject=test, multisubject=false, multisubjectmax=100000, js=true, msgs=2, msgsize=128 B, pubs=1, subs=0, stream=benchstream, maxbytes=1.0 GiB, storage=file, syncpub=false, pubbatch=100, jstimeout=30s, pull=false, consumerbatch=100, push=false, consumername=natscli-bench, replicas=1, purge=false, pubsleep=0s, subsleep=0s, dedup=false, dedupwindow=2m0s]
15:20:01 Starting publisher, publishing 2 messages
Finished 0s [===============================================================================================================================================================================] 100%
Pub stats: 2,739 msgs/sec ~ 342.45 KB/sec
At a later time, a subscriber can read old messages from the subject:
$ kubectl exec -it deployment/<release-name>-box -- nats sub test --all
15:22:28 Subscribing to JetStream Stream holding messages with subject test starting with the first message received
[#1] Received JetStream message: stream: benchstream seq 1 / subject: test / time: 2025-04-02T15:20:01Z
[#2] Received JetStream message: stream: benchstream seq 2 / subject: test / time: 2025-04-02T15:20:01Z
Additional configurations
The NATS Helm chart is highly configurable via merge and patch templating strategies. Refer to the NATS README.md to know more about these advanced templating features.
Operations
Check connectivity
As explained earlier, the Helm chart deploys nats-box. You can use the NATS CLI utility to verify the connectivity:
$ kubectl exec -it deployment/<release-name>-box -- nats server check connection
OK Connection OK:connected to nats://<release-name>:4222 in 825.666µs OK:rtt time 101.875µs OK:round trip took 0.000100s | connect_time=0.0008s;0.5000;1.0000 rtt=0.0001s;0.5000;1.0000 request_time=0.0001s;0.5000;1.0000
You can also check the connectivity by sending and receiving messages. Start a subscriber waiting to receive messages from the “test” subject:
$ kubectl exec -it deployment/<release-name>-box -- nats sub test
15:10:06 Subscribing on test
On a different terminal, publish a message to the “test” subject:
$ kubectl exec -it deployment/<release-name>-box -- nats pub test 'hello world'
15:10:12 Published 11 bytes to "test"
The subscriber should receive the message:
$ kubectl exec -it deployment/<release-name>-box -- nats sub test
15:10:06 Subscribing on test
[#1] Received on "test"
hello world
Upgrade the chart
In general, an in-place upgrade of your NATS installation can be performed using the built-in Helm upgrade workflow:
helm upgrade <release-name> oci://dp.apps.rancher.io/charts/nats
Be aware that changes from version to version may include breaking changes in NATS itself or in the Helm chart templates. In other cases, the upgrade process may require additional steps to be performed. Refer to the official release notes and always check the Helm chart’s Upgrade notes before proceeding with an upgrade.
Uninstall the chart
Removing an installed NATS Helm chart release is simple:
helm uninstall <release-name>
When you enable JetStream or NATS Resolver, the NATS servers are deployed using Volume Claim Templates. These PVCs are not directly controlled by Helm and they are not removed when uninstalling the related chart.
When you are ready to remove the PVCs and their data, you will need to explicitly delete them:
kubectl delete pvc --selector app.kubernetes.io/instance=<release-name>
