SUSE Application Collection: kubectl

Get started

kubectl is a command line tool for communicating with a Kubernetes cluster’s control plane, using the Kubernetes API.

Before exploring the container’s possibilities, let’s start by deploying the default configuration:


docker run \
    --interactive \
    --tty \
    --rm \
    --name <container-name> \
    dp.apps.rancher.io/containers/kubectl:1.35

Check our authentication guide if you need to configure Application Collection OCI credentials in your Docker client.

Container overview

Since there is no official upstream container for kubectl, our container is built from scratch using a SUSE Linux BCI Micro base image and includes our best practices.

Apply a template from a file

To run the kubectl container, execute the following command:


docker run \
    --interactive \
    --tty \
    --rm \
    --name <container-name> \
    --network host \
    --entrypoint "/bin/bash" \
    --volume ~/.kube/config:/.kube/config:ro \
    --env KUBECONFIG=/.kube/config \
    dp.apps.rancher.io/containers/kubectl:1.35

We shared the host’s kubeconfig file and set the KUBECONFIG environment variable as required by the kubectl CLI to authenticate and reach your Kubernetes clusters. We also shared the host’s network to ensure the kubectl container can communicate with the cluster’s API server.

Then, we’ll create an NGINX deployment template file to test the container’s ability to create resources in the Kubernetes cluster.

nginx-deployment.yaml


apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx
  labels:
    app: nginx
spec:
  replicas: 1
  selector:
    matchLabels:
      app: nginx
  template:
    metadata:
      labels:
        app: nginx
    spec:
      imagePullSecrets:
      - name: application-collection
      containers:
      - name: nginx
        image: dp.apps.rancher.io/containers/nginx:1.29.3
        ports:
        - containerPort: 80

Use the following commands to copy the template inside the kubectl container and apply it from there.


docker cp nginx-deployment.yaml <container-name>:/tmp/nginx-deployment.yaml

Then, within the kubectl container, apply the NGINX deployment manifest:


kubectl apply -f /tmp/nginx-deployment.yaml

Run the commands below to check that the Deployment was created and its Pod is running with:


$ kubectl get deployments
NAME    READY   UP-TO-DATE   AVAILABLE   AGE
nginx   1/1     1            1           5s

$ kubectl get pods
NAME                     READY   STATUS    RESTARTS   AGE
nginx-69b67d89cc-279c7   1/1     Running   0          5s

Scale up the deployment

We deployed NGINX with one Pod. Now, we will scale up the deployment to three Pods with:


kubectl scale deployments/nginx --replicas 3

Then, we can check the diff of the modified Deployment against its original template by executing:


kubectl diff -f /tmp/nginx-deployment.yaml

Delete the deployment

Once we are done testing the NGINX Deployment, it can be removed with the following command:


kubectl delete -f /tmp/nginx-deployment.yaml

The kubectl container can be stopped and removed as well:


docker rm -f <container-name>
